ELECTRICVEHICLE-BATTERYCHARGERExternalChargerRepairs

EXTERNALCHARGERREPAIRS

SeeGeneralWarningsonpage1-2.

WARNING

•Knowledgeofbatterychargerwiringandcomponentterminologyisrequiredbeforeattemptingany

repair(Figure15-5,Page15-8).

•Priortoservicingthecharger,disconnecttheDCplugfromthevehiclechargerreceptacleandthe

ACcordfromtheACoutlet.

NOTE:Thischargerhasnointernalstoserviceorrepair.Itonlyhasafewexternalrepairsthatcanbeperformed.

Ifaninternalcomponentneedsrepair,thechargermustbereplaced.

2790

Figure15-8ExternalHigh-FrequencyChargerComponents

TERMINALBLOCKCOVERREMOVAL

1.DisconnectDCcord(1)fromvehicle.

2.DisconnectACcord(2)fromACoutlet.

3.Pushinmountingtabs(Figure15-9,Page15-20)toreleasecover(3)fromterminalblock(4).

2019PrecedentVillager2MaintenanceandServiceManualPage15-19
