TransaxleInstallationGASOLINEVEHICLE-TRANSAXLE
1
1
3
2
3063
Figure24-13TransaxleMountingBolts
TRANSAXLEINSTALLATION
SeeGeneralWarningsonpage1-2.
1.Installationisreverseofremovalprocedure.Whenattachingtransaxletopowertrain,initiallyinstalltheeightbolts
(1)nger-tight(Figure24-13,Page24-12).Then,tightenfastenersinthefollowingorder:
1.1.Tightenthetwobolts(1)atclutchplate(3)to50ft·lb(68N·m).
1.2.Tightenthefourbolts(1)atenginepan(2)to50ft·lb(68N·m).
1.3.Tightenthetwobolts(1)atmuferbracketto50ft·lb(68N·m).
1.4.Tightenthegovernorcablebracket(2)andFNR/acceleratorcablebracket(2)boltsto50ft·lb(68N·m)
(Figure24-6,Page24-9).
1.5.Tightenleafspringhardwareto19ft·lb(26N·m)atchassisandshackle.SeeRearSuspensionsection.
1.6.Tightenlowernutsofshockabsorbersuntilcushionsexpandtobethesamediameterasthemounting
washers.
1.7.Tightentransaxledrainplugto17ft·lb(23.5N·m).
2.Filltransaxlewithappropriatetypeandvolumeofoil.SeeOilChange–Transaxleonpage24-2.
3.Ensurethatallwiresandcablesaresecuredproperlywithwireties.SeefollowingWARNING.
WARNING
•Ifwiresandcablesareremovedorreplacedmakesuretheyareproperlyroutedandsecuredtovehicle
frame.Failuretoproperlyrouteandsecurewiresandcablescouldresultinvehiclemalfunction,
propertydamageorpersonalinjury.
4.Connectbatteryandsparkplugwire(s).
SeeConnectingtheBattery-GasolineVehiclesonpage1-3.
5.Checkgovernoradjustmentandcorrectifnecessary.SeeGovernorCableInstallationandAdjustment,
Section21,Page21-9.
6.CheckengineRPMsetting.Adjustifnecessary.SeeEngineRPMAdjustment,Section21,Page21-13.
Page24-122019PrecedentVillager2MaintenanceandServiceManual
