AirIntakeSystemGASOLINEVEHICLE-FUELSYSTEM

5.Theaircleaner(1)issecuredtothefuelbucketwithscrews(2).Accesstothescrewsrequiresthatthekickplate

beremoved.SeeKickPlateRemovalonpage4-10.

AIRINTAKESYSTEMINSTALLATION

WARNING

•Intakehose(3)ismadefromaspecialreretardantneoprenematerial.Useofanyhosethatdoes

notmeetClubCar,LLCspecicationscouldcreatearehazard.

•Improperorientationofthehoseclamp(5)mayresultinfueltankdamage(Figure21-11,Page21-16).

1.Positionaircleaner(1)insidethefuelbucket(Figure21-9,Page21-14).Securewithscrews(2).Tighten

screwsto2.7ft·lb(3.5N·m).

2.Installhose(3)onaircleaner(1)andsecurewithclamp(4).

3.Installhose(3)onthrottlebodyandsecurewithclamp(5)orientedasshown(Figure21-11,Page21-16)

withtabsup.

4.Installkickplate.SeeKickPlateInstallationonpage4-10.

3192

Figure21-11HoseClampOrientationatThrottleBody

Page21-162019PrecedentVillager2MaintenanceandServiceManual
