ELECTRICVEHICLE-MOTORMotor

731

Figure16-3LowerAxle

9.Removetheboltsandlockwashersthatsecurethemotortothetransaxle(Figure16-24,Page16-17).See

followingCAUTION.

CAUTION

•Donotpositionngersundermotorwhenslidingmotoroffoftheinputshaftinstep9.Fingersmay

getpinchedwhenmotordisengages.

10.Carefullyslidethemotorawayfromthetransaxleuntilthemotorsplinedisengagestheinputshaftandremove

themotorfromthevehicle.

748

Figure16-4SpeedSensorMagnet

749

Figure16-5EndCap

MOTORDISASSEMBLY

1.Beforebeginningdisassembly,placematchmarksonthemotorendcapandmotorframe.

2.Removespeedsensorandmagnet.

2019PrecedentVillager2MaintenanceandServiceManualPage16-5
