Starter/Generator

GASOLINEVEHICLE-ELECTRICAL

COMPONENTS

Figure19-5PullBrushesAwayFromCenteroftheCommutatorEndCover

DISASSEMBLYOFTHESTARTER/GENERATORTOSERVICETHE

ARMATURE/COMMUTATOR

1.Removethecommutatorendcovertopreventdamagetothebrushesandarmature.SeeCommutatorEnd

Coveronpage19-2.

2.Toseparatearmatureandoutputendcoverassemblyfromtheeldcoilhousing,rstremovethetwosecuring

bolts(43).Carefullyremovearmatureandoutputendcoverassemblyfromtheeldcoilhousingsocomponents

arenotdamaged.

3.Toseparatearmature(33)fromoutputendcover(36),removenut(41),lockwasher(40),pulley(39).Itmaybe

necessarytousethewedgeattachmenttooltoremovethepulleyfromtheshaft.

4.Removetheinternalretainingring(32)toreleasethebearing(35)andarmature(33)fromtheoutputendcover

(36).(Figure19-6,Page19-5).

Page19-42019PrecedentVillager2MaintenanceandServiceManual
