Starter/Generator
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
20
23
24
28
27
30
29
23
25
487
Figure19-1CommutatorEndCover
Figure19-2BrushCoversandBrushes
BRUSHINSPECTIONANDREPLACEMENT
1.Visuallyinspectbrushes.Replacebrushesthatarecrackedorseverelychipped.
2.Measurethelengthofeachbrush.Replacethebrushsetifabrushislessthan0.375inch(9.5mm)(Figure
19-3,Page19-2).
0
1
1/2
1/2
Figure19-3InspectBrushesandMeasureLength
BRUSHSPRINGINSPECTIONANDREPLACEMENT
1.Visuallyinspectsprings.Replaceallfourspringsifanyspringisdiscoloredfromheat(straworbluishincolor).
2.Installthefourbrushes(27)intotheirholdersandinsertthefourbrushsprings(28)(Figure19-2,Page19-2).
Usingaspringscale,testbrushspringtension.Ifanyspringhasatensionlessthan24ozf(0.68kgf),replaceall
foursprings(Figure19-4,Page19-3).SeefollowingCAUTION.
Page19-22019PrecedentVillager2MaintenanceandServiceManual
