VoltageRegulator

GASOLINEVEHICLE-ELECTRICAL

COMPONENTS

2432

Figure19-18VoltageRegulator

VOLTAGEREGULATORINSTALLATION

1.Positionthevoltageregulator(1)andinstallthemountingscrew(2)(Figure19-18,Page19-16).Tightenscrewto

23in·lb(2.6N·m).

2.Connectthevoltageregulatorthree-pinconnector(3)tothewireharness.

3.Connectbatteryandsparkplugwire(s).

SeeConnectingtheBattery-GasolineVehiclesonpage1-3.

4.PlaceForward/ReversehandleinNEUTRALandplacetheneutrallockoutcamintheMAINTENANCEposition.

Starttheengineandcheckregulatorforproperfunctioningasdescribedinthevoltageregulatortestprocedure.

SeeTestProcedure13–VoltageRegulatoronpage18-27.

Page19-162019PrecedentVillager2MaintenanceandServiceManual
