GASOLINEVEHICLE-CLUTCHESDriveClutch
23
2
3
4
1
602
Figure23-10PrimaryandSecondaryWeights,Wave
WasherandPin
6.Removetheretainingring(6)fromtheshaftofthexedsheave(18)andslidethemoveablesheave(13)offthe
shaft(Figure23-3,Page23-4).SeefollowingNOTE.
NOTE:Ifthemoveablesheaveisremovedfromthehubofthexedsheave,thespiralback-uprings(11)mustbe
replacedwithnewrings(Figure23-3,Page23-4).
7.Removethespacer(14)andspring(15)(Figure23-3,Page23-4).
8.Useascribeorsmallpicktoremovethespiralbackuprings(11)fromeachendoftheboreinthexedsheave
(Figure23-3,Page23-4).SeealsoFigure23-11,Page23-9.Discardtherings.
605
Figure23-11SpiralBack-upRings
INSPECTIONOFDRIVECLUTCHPARTS
1.Inspecttheidlerspacer(17)forsmoothness(Figure23-3,Page23-4).
2.Inspecttheboreofthemoveablesheave(13)forscarringorwear.Themoveablesheavemustbereplacedifthe
boreisworntoadiameterof0.883in.(22.4mm)orlarger(Figure23-3,Page23-4).
3.Inspectthesteelshaftonthexedsheave(18).Thereshouldbenomeasurablewearanywhereontheshaft.
Replacetheshaftifitisworn,scratched,ordamaged.
4.Inspectthethrustwasher(9)forwear.Ifitiswornmorethan0.030in.(0.76mm),turnitoverorreplaceitwith
anewone.
2019PrecedentVillager2MaintenanceandServiceManualPage23-9
