KickPlate–EFIGasolineVehiclesBODYANDTRIM

KICKPLATE–EFIGASOLINEVEHICLES

SeeGeneralWarningsonpage1-2.

KICKPLATEREMOVAL

1.Removeoormat.SeeFloorMatandRetainersonpage4-8.

2.Removethreescrews(1)thatholdthekickplate(2)tothevehicle(Figure4-7,Page4-10).

3.Removethetwofrontscrews(3)thatholdthebeautypaneltothevehicle.Raisetheforwardportionoftherear

beautypaneltodisengageitfromthetabsontheupperportionofthekickplate.

4.Removekickplatefromvehicle.

KICKPLATEINSTALLATION

1.Positionthekickplate(2)onthevehicleandsecurewiththreescrews(1).Ensurefrontloweredgeofrearbeauty

panelmateswiththekickplate(Figure4-7,Page4-10).Tightenscrewsto3.3ft·lb(4.5N·m).

2.Installtwofrontscrews(3)tosecuretherearbeautypanel.Tightenscrewsto3.7ft·lb(5N·m).

3.Installoormat.SeeFloorMatandRetainersonpage4-8.

620a

Figure4-7KickPlate–EFIGasolineVehicles

Page4-102019PrecedentVillager2MaintenanceandServiceManual
