GASOLINEVEHICLE-ENGINESnubber

SNUBBER

SeeGeneralWarningsonpage1-2.

NOTE:Thesnubberisinstalledonthegasolinevehicleonly.

SNUBBERREMOVAL

1.Supportthepowertrainwithaoorjackundertheenginepan(1)sothatthesnubber(2)israisedslightlyand

doesnotrestonthevehicleframe(Figure20-14,Page20-15).

2.Removethetwobolts(3)andtwolocknuts(4)securingthesnubberbracket(5)totheenginepan(1).

3.Slidesnubber(2)andbracket(5)assemblytowardbatterytoremoveitfromvehicle.

4.Slidesnubber(2)offbracket(5).

SNUBBERINSTALLATION

1.Slidesnubber(2)ontobracket(5)(Figure20-14,Page20-15).

2.Installbracketandsnubberassemblyontoenginepan(1).

3.Tightenlocknuts(4)from20to25ft·lb(27.1to33.9N·m).

3039

Figure20-14Snubber

2019PrecedentVillager2MaintenanceandServiceManualPage20-15
