GASOLINEVEHICLE-FUELSYSTEMCarbonCanister
21
CARBONCANISTER
WARNING
•Ifthecarboncanisterisdamaged,onlyuseanOEM(ClubCar)replacementthatisspecically
designedandapprovedforuseonthisvehicle.Donotattempttorepairit.Seethefollowingcanister
removalprocedure.
CARBONCANISTERREMOVAL
1.Disablethevehicle.SeeDisablingtheVehicleonpage1-3.
2.Raiseorremoveseatbottomfromvehicle.
3.Removehoseclamps(1),securingthreehoses(2,3,and4)tocanister(5),anddisconnecthoses(Figure
21-16,Page21-27).
4.Pushorpullcanisterfrommountingbracket(6).
1
1
3
4
A
6
5
5
2
2
1
3
4
DetailA:SideView
1.Clamp2.VentTube(FuelTanktoCanister)3.VentTube(CanistertoEngine)4.VentTube(CanistertoAtmosphere)5.CarbonCanister6.
MountingBracket
2447
Figure21-16CarbonCanister,HosesandRouting
CARBONCANISTERINSTALLATION
1.Aligncanistermountingtabswithslotsinmountingbracket(6)andpushcanister(5)intobracket(Figure21-16,
Page21-27).Forceitinuntilfullyseated.
2019PrecedentVillager2MaintenanceandServiceManualPage21-27
