Starter/Generator

GASOLINEVEHICLE-ELECTRICAL

COMPONENTS

B B

1.Measureeachpositionintwoplaces,90degreesapart

496

Figure19-10InspectCommutator

ARMATUREGROUNDTEST

CAUTION

•Donotsubmergearmatureinsolvent.

NOTE:Beforetesting,wipethearmaturewithacleanclothandremovecarbondustandmetalparticlesfrombetween

commutatorbars.

Usingamultimeterseton200ohms,placethepositive(+)probeonthecommutatorbarsandthenegative(–)probe

onthearmaturecore.Thereadingshouldbenocontinuity.Ifthereadingisincorrect,replacethearmatureandthe

twobearings(Figure19-11,Page19-9).

Page19-82019PrecedentVillager2MaintenanceandServiceManual
