EngineControlLinkagesGASOLINEVEHICLE-FUELSYSTEM

ENGINECONTROLLINKAGES

SeeGeneralWarningsonpage1-2.

DANGER

•Toensurethevehicledoesnotrunoveryouwhileyoudisconnectoradjusttheacceleratorpush

rod,dothefollowing:

–TurnkeyswitchOFFandremovekey,placeForward/ReversehandleintheNEUTRALposition,

andchockthewheelspriortoservicingthevehicle.

–Disconnectbatterycables,negative(–)cablerst.

–Disconnectthesparkplugwirefromthesparkplug.

–

SeeDisconnectingtheBattery-GasolineVehiclesonpage1-3.

GENERALINFORMATION

Forpropervehicleoperation,itisimportanttheacceleratorcable,governorlinkage,andthrottleadjustmentsaredone

correctlyandinthepropersequence.SeefollowingCAUTION.

CAUTION

•Improperadjustmentcanresultinpoorvehicleperformanceand/ordamagetotheenginecomponents.

3123

Figure21-4EngineControlLinkages–Villager2EFIvehicles

Page21-82019PrecedentVillager2MaintenanceandServiceManual
