DriveClutchGASOLINEVEHICLE-CLUTCHES

DRIVECLUTCH

SeeGeneralWarningsonpage1-2.

1.Screw,3/8-24x5.75,Patch10.Retainer

2.Washer,3/8,TypeA,Flat11.Ring,SpiralBackup

3.Washer,Hard,M1012.Bushing,Split,DriveClutch

4.CapPlug13.Sheave,Moveable,Drive

5.DriveHubAssy,DriveClutch14.Spacer,FixedFaceShaft

6.Ring,0.810in.(20.5mm)InternalRetaining15.Spring,DriveClutch

7.DriveClutchButton16.NoItemtoShow

8.DriveClutchWeight17.Spacer,Idler,Drive

9.ThrustWasher18.Sheave,Fixed,Drive

2960

Figure23-3DriveClutch–ExplodedView

Page23-42019PrecedentVillager2MaintenanceandServiceManual
