EngineControlLinkagesGASOLINEVEHICLE-FUELSYSTEM

2.3.Pushbellowsbackontothreadedendofcablehousing.

2.4.Connect“Z”ttingofgovernorcable(1)togovernorarm(4).

3.Loosenadjustmentscrewjamnuts(6and10)andbackoffthrottlestopscrew(7)andpowerlimiterscrew(11)

severalturns(Figure21-7,Page21-10).

4.Rotategovernorarm(4)counterclockwiseuntilitstopsandholdinthisposition(Figure21-7,Page21-10).

5.Adjustgovernorcablejamnutsuntilthrottlelever(2)isat“wideopenthrottle”(WOT)(Figure21-5,Page21-9)

andtightenthegovernorcablejamnutsto36in·lb(4.0N·m).

6.Whilestillholdingthisposition,adjustpowerlimiterscrew(11)(Figure21-7,Page21-10)tosetdistance(B)

at2.87in.(±0.039)(1.4mm(±1))asshown(Figure21-5,Page21-9)betweenthrottlelever(2)andthrottle

bodybracket(3).Tightenlimiterscrewjamnut(10)to36in·lb(4.0N·m).

7.Releasegovernorarm(4)toreturnto“idle”position.

8.Adjustgap(A)betweengovernorarm(4)andthrottlestopscrew(7)to0.055in.(±0.039)(1.4mm(±1))asshown

(Figure21-7,Page21-10).Tightenstopscrewjamnut(6)to36in·lb(4.0N·m).

9.CheckengineRPMadjustment.SeeEngineRPMAdjustmentonpage21-13.

A=0.055in.±0.039(1.4mm±1)

3130

Figure21-6GovernorandAcceleratorCablesAtGovernor

Arm

3131

Figure21-7ThrottleStopScrewGap

ACCELERATORCABLE

AcceleratorCableRemoval

1.TurnthekeyswitchtotheOFFpositionandremovethekey,placetheForward/ReversehandleintheNEUTRAL

position,andchockthewheels.

2.Disconnectbatteryandsparkplugwire(s).

SeeDisconnectingtheBattery-GasolineVehiclesonpage1-3.

3.Attransaxle:

3.1.Unhookspringttingofacceleratorcable(8)fromgovernorarm(4)(Figure21-6,Page21-10).

3.2.Unsnapacceleratorcable(8)fromFNR/acceleratorcablebracket(9).

4.Atpedalgroup:

4.1.Accessthepedalgroupanddisconnectacceleratorcableclipfromtheacceleratorpedal.SeePedal

GroupRemovalonpage5-4.

4.2.Loosenjamnutssecuringacceleratorcabletounderbodyandremoveacceleratorcable(9)fromvehicle

(Figure5-4,Page5-5).

Page21-102019PrecedentVillager2MaintenanceandServiceManual
