ReverseBuzzer

ELECTRICVEHICLE-ELECTRICAL

COMPONENTS

REVERSEBUZZER

SeeGeneralWarningsonpage1-2.

TESTINGTHEREVERSEBUZZER

See12-29.

REVERSEBUZZERREMOVAL

1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles

onpage1-4.

2.Removeinstrumentpanel.SeeKeySwitchRemovalonpage13-1.

3.Disconnectthe18-gaugepinkandorange/whitewiresfromreversebuzzer.

4.Removethetwoscrewsfromthereversebuzzer.Removethereversebuzzerfromthedashpanel.

REVERSEBUZZERINSTALLATION

1.Installthereversebuzzerinthereverseorderofremoval.Pinkwiremustbeconnectedtothepositiveterminal.

Tightenscrewsto4in·lb(0.45N·m).

2.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnectingtheBatteries–

ElectricVehiclesonpage1-4.

(Viewedfromundersideofinstrumentpanel)

A.PinkB.Orange/White

711

Figure13-7ReverseBuzzer

Page13-82019PrecedentVillager2MaintenanceandServiceManual
