Page #338 background imageLoading...
Page #338 background image
1G-15 Fuel System:
Specifications
Service Data
B718H11707001
Injector + Fuel Pump + Fuel Pressure Regulator
Fuel
Tightening Torque Specifications
B718H11707002
NOTE
The specified tightening torque is also described in the following.
“Fuel Pump Components (Page 1G-10)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications in Section
0C (Page 0C-7)”.
Item Specification Note
Injector resistance 11 – 13 at 20 °C (68 °F)
Fuel pump discharge amount 166 ml (5.6/5.8 US/lmp oz) and more/10 sec.
Fuel pressure regulator operating
set pressure
Approx. 300 kPa (3.0 kgf/cm
2
, 43 psi)
Item Specification Note
Fuel type
Use only unleaded gasoline of at least 87 pump octane or 91
octane (R/2 + M/2) or higher rated by the research method.
Gasoline containing MTBE (Methyl Tertiary Butyl Ether), less
than 10% ethanol, or less than 5% methanol with
appropriate cosolvents and corrosion inhibitor is permissible.
E-03, 28, 33
Gasoline used should be graded 91 octane or higher. An
unleaded gasoline type is recommended.
Others
Fuel tank capacity Including reserve
18.5 L (4.9/4.1 US/lmp gal) E-33
19 L (5.0/4.2 US/lmp gal) Others
Fastening part
Tightening torque
Note
Nmkgf-mlb-ft
Fuel pump mounting bolt 10 1.0 7.0 )(Page 1G-12)
