Suzuki GSF1250 Service Manual

5C-1 Clutch:
Transmission / Transaxle
Clutch
Precautions
Precautions for Clutch System
B718H15300001
Refer to “General Precautions in Section 00 (Page 00-1)”.
Clutch Fluid (Brake Fluid) Information
B718H15300002
WARNING
!
• This clutch system is filled with an ethylene glycol-based DOT 4 brake fluid. Do not use or mix
different types of fluid such as silicone-based or petroleum-based.
• Do not use any brake fluid taken from old, used or unsealed containers. Never reuse brake fluid left
over from the last servicing or stored for long periods.
• When storing brake fluid, seal the container completely and keep away from children.
• When replenishing brake fluid, take care not to get dust into fluid.
• When washing clutch components, use fresh brake fluid. Never use cleaning solvent.
CAUTION
!
Immediately and completely wipe off any brake fluid contacting any part of the motorcycle. The brake
fluid reacts chemically with paint, plastics and rubber materials, etc., and will damage them severely.

Suzuki GSF1250 Specifications

General

Displacement	1255 cc
Bore x Stroke	79.0 mm x 64.0 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Transmission	6-speed, constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Overall Length	2130 mm
Overall Width	790 mm
Seat Height	805 mm
Wheelbase	1485 mm
Fuel Tank Capacity	19.0 L
Starter	Electric
Final Drive	Chain
Ignition	Electronic ignition (transistorized)
Engine Type	4-stroke, liquid-cooled, DOHC
Ground Clearance	135 mm
