Suzuki GSF1250 Service Manual

2C-12 Rear Suspension:
Specifications
Service Data
B718H12307001
Unit: mm (in)
Tightening Torque Specifications
B718H12307002
NOTE
The specified tightening torque is also described in the following.
“Rear Suspension Components (Page 2C-1)”
“Rear Suspension Assembly Construction (Page 2C-2)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque Specifications in Section
0C (Page 0C-7)”.
Item Standard Limit
Rear shock absorber spring
adjuster
GSF1250/A 3rd position
GSF1250S/SA 4th position —
Rear shock absorber damping
force adjuster
Rebound 1-1/4 turns out from stiffest position —
Rear wheel travel 136 (5.4) —
Swingarm pivot shaft runout — 0.3 (0.01)
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Rear shock absorber mounting nut
50 5.0 36.0
)(Page 2C-3) /
)(Page 2C-5) /
)(Page 2C-9)
Cushion lever mounting nut
78 7.8 56.5
)(Page 2C-3) /
)(Page 2C-5) /
)(Page 2C-9)
Cushion rod mounting nut
78 7.8 56.5
)(Page 2C-5) /
)(Page 2C-9)
Swingarm pivot nut 100 10.0 72.5 )(Page 2C-8)

Suzuki GSF1250 Specifications

General

Displacement	1255 cc
Bore x Stroke	79.0 mm x 64.0 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Transmission	6-speed, constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Overall Length	2130 mm
Overall Width	790 mm
Seat Height	805 mm
Wheelbase	1485 mm
Fuel Tank Capacity	19.0 L
Starter	Electric
Final Drive	Chain
Ignition	Electronic ignition (transistorized)
Engine Type	4-stroke, liquid-cooled, DOHC
Ground Clearance	135 mm
