Suzuki GSF1250 Service Manual

9D-5 Exterior Parts:
Engine Sprocket Outer Cover Cushion Construction
B718H19406008
Fastener Removal and Installation
B718H19406003
Removal
1) Depress the head of fastener center piece (1).
2) Pull out the fastener (2).
Installation
1) Let the center piece stick out toward the head so that
the pawls “A” closes.
1
2
I718H1940031-01
1. Engine sprocket outer cover cushion
: Clear adhesive surface before adhering the tape cushion.
2. Engine sprocket outer cover
1
2
I649G1940005-02
“A”
I649G1940006-02
