Suzuki GSF1250 Service Manual

2D-1 Wheels and Tires:
Suspension
Wheels and Tires
Precautions
Precautions for Wheel and Tire
B718H12400001
WARNING
!
• Proper tire pressure and proper tire loading are important factors. Over loading tire can lead to tire
failure and loss of motorcycle control.
• Under-inflated tires make smooth cornering difficult, and can result in rapid tire wear.
• Over-inflated tires have a smaller amount of tire in contact with the load, which can contribute to
skidding and loss of control.
• Replace the wheel when wheel runout exceed the service limit or if find damage such as distortion,
crack, nick or scratch.
• When tire replacement is necessary, the original equipment type tire should be used.
• Do not mix different types of tires on the same vehicle such as radial and bias-belted tires except in
emergencies, because handling may be seriously affected and may result in loss of control.
• Replacement wheel must be equivalent to the original equivalent wheel.

Suzuki GSF1250 Specifications

General

Displacement	1255 cc
Bore x Stroke	79.0 mm x 64.0 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Transmission	6-speed, constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Overall Length	2130 mm
Overall Width	790 mm
Seat Height	805 mm
Wheelbase	1485 mm
Fuel Tank Capacity	19.0 L
Starter	Electric
Final Drive	Chain
Ignition	Electronic ignition (transistorized)
Engine Type	4-stroke, liquid-cooled, DOHC
Ground Clearance	135 mm
