ABS: 4E-12
Component Location
ABS Components Location
B718H14503001
2
1
3
5
4
6
7
I718H1450119-02
1. ABS control unit/HU 4. Front wheel speed sensor 7. Rear wheel speed sensor rotor
2. Mode select coupler 5. Front wheel speed sensor rotor
3. SDS coupler 6. Rear wheel speed sensor
