Suzuki GSF1250 Service Manual

Lighting Systems: 9B-7
Brake Light Bulb / Taillight Bulb Replacement
B718H19206008
CAUTION
!
When you touch the bulb with your bare
hands, clean the bulb with a cloth moistened
with alcohol or soap water to prevent
premature bulb failure.
1) Remove the seat. Refer to “Exterior Parts Removal
and Installation in Section 9D (Page 9D-6)”.
2) Remove the tool set (1).
3) Remove the bulb socket by turning it
counterclockwise.
4) Replace the bulb (2).
5) Reinstall the removed parts.
License Plate Light Components
B718H19206009
1
I718H1920051-01
I718H1920020-01
2
I718H1920021-01
2
3
1
I649G1920023-03
1. License plate light bulb (12 V 5 W) 2. Lens cover 3. Lens

Suzuki GSF1250 Specifications

General

Displacement	1255 cc
Bore x Stroke	79.0 mm x 64.0 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Transmission	6-speed, constant mesh
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	180/55ZR17M/C (73W), tubeless
Overall Length	2130 mm
Overall Width	790 mm
Seat Height	805 mm
Wheelbase	1485 mm
Fuel Tank Capacity	19.0 L
Starter	Electric
Final Drive	Chain
Ignition	Electronic ignition (transistorized)
Engine Type	4-stroke, liquid-cooled, DOHC
Ground Clearance	135 mm
