Brother PR655 Service Manual

3 - 50
Needle bar unit
Main unit
Assembly Assembly
1 Case guide UL assembly
1. Attach the thread take-up guide 1 to the case guide UL 2 with the 2
screws 1.
*Key point
• Check that these are attached in the direction shown in the
photo.
1
Torque
1.18 — 1.57 N-m
1
1
2
Screw, Pan
M4X8

Brother PR655 Specifications

General

Number of Needles	6
Built-in Designs	25
USB Port	Yes
LCD Display	Yes
Type	Embroidery Machine
Built-in Fonts	28
Maximum Speed	1000 stitches per minute
Embroidery Area	300mm x 200mm
