Error message list
Error message list See page Error message list See page
The pattern is too large for the extra large
embroidery frame.
5 - 21
Main motor rotate error.
5 - 12
Change to a larger embroidery frame.
5 - 21
Main motor encoder signal error.
5 - 28
USB media is not loaded. Load USB media.
5 - 19
Main motor encoder connect error.
5 - 28
This USB media cannot be used.
5 - 19
Main motor current error.
5 - 29
Not enough space. Delete some patterns or
use a different USB media.
5 - 19
Trimming sensor error.
5 - 14
The USB media was changed. Do not
change the USB media while it is being
read.
5 - 19
Machine PCB power off.
Check Main PCB
The USB media is write-protected so the
data cannot be saved. Cancel the write-
protection before trying to save the data.
5 - 19
Wiper error.
5 - 15
The USB media is write-protected so the
data cannot be deleted. Cancel the write-
protection before trying to delete the data.
5 - 19
Needle threader error.
5 - 16
USB media error.
5 - 19
Picker error.
5 - 17
Preventive maintenance is recommended.
Chapter 6
Main motor speed error.
5 - 12
Machine PCB reset.
Check Main PCB
Power supply voltage error.
(24V high)
5 - 31
Inappropriate needle stop position.
5 - 12
Power supply voltage error.
(24V low)
5 - 31
Needle bar case position error.
5 - 8
Power supply voltage error.
(40V high)
5 - 31
Needle case motor has been locked.
5 - 8
Power supply voltage error.
(40V low)
5 - 31
Needle bar case home position error.
5 - 8
Panel communication error.
5 - 30
X-axis home position error.
5 - 10
Communication time out error.
5 - 30
Y-axis home position error.
5 - 27
Data receiving command error.
5 - 30
XY moving error.
5 - 12
Communication error.
5 - 30
EEPROM read/write error.
Check Main PCB
Check upper and bobbin thread.
5 - 9
