Brother PR655 Service Manual

Failure Investigation for Electronic Parts
Failure Investigation
for Electronic Parts
Failure Investigation
for Electronic Parts
5 - 12
The main shaft does not rotate normally.
The main shaft does not rotate
normally.
Change the main shaft encoder.
N
Y
Is the main shaft encoder deformed,
bent, or damaged due to contact?
Connect it properly.
N
Y
Is the main shaft sensor's lead properly
connected to CN19 on the main PCB?
Y
Connect it properly.
N
Is the main motor's lead properly
connected to the power supply
PCB's lead?
Connect it properly.
N
N
Is the lead which connect the
power supply PCB and the main
motor properly connected to CN4
on the power supply PCB?
Y
Change the main shaft
sensor PCB.
Y
Does the machine function normally
when the main shaft sensor PCB is
replaced with a reliable one?
Connect it properly.
N
Y
Is the lead which connect the power
supply PCB and the main PCB properly
connected to CN27 on the main PCB
and CN3 on the power supply PCB?
To the next page

Brother PR655 Specifications

General

Number of Needles	6
Built-in Designs	25
USB Port	Yes
LCD Display	Yes
Type	Embroidery Machine
Built-in Fonts	28
Maximum Speed	1000 stitches per minute
Embroidery Area	300mm x 200mm
