Brother PR655 Service Manual

6 - 11
Maintenance
Maintenance &
Replacement
Maintenance &
Replacement
Maintenance point (Every day)
3. Maintenance point by end user (Every day)
Cleaning of knives and rotary hook
Maintenance
Remove the needle plate. Use the included cleaning
brush to remove any lint and dust from knives and
rotary hook.
Oil rotary hook
Maintenance
Remove bobbin case and apply 1 drop of oil into the
hook race. Then spread it on whole hook with cloth.
Cleaning of bobbin case
Maintenance
Remove any lint and dust between tension-adjusting
spring and bobbin case, whenever one prewound
bobbin (coats) is used.
Clean up
Clean up
Oil here
Clean up

Brother PR655 Specifications

General

Number of Needles	6
Built-in Designs	25
USB Port	Yes
LCD Display	Yes
Type	Embroidery Machine
Built-in Fonts	28
Maximum Speed	1000 stitches per minute
Embroidery Area	300mm x 200mm
