Connection
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │111
E.6.3 PERCEPTRON V5 SCANNER (ABSOLUTE SE ONLY)
Hardware installation:
1 Ethernet port must be available
Install the arm as described in this manual.
1. Mount the V5 Perceptron scanner through the TKJ connector
2. Lock the TKJ connector
3. Select the Scanner
