Hexagon Absolute Arm RS5 User Manual

Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │213
I.3.3 ISO 10360-8 ANNEX D SCANNING SYSTEM ACCURACY
The following data represent the accuracies of the different sizes and levels of Absolute Arm, according to
the ISO 10360-8 Annex D standard.
Precision test is done on a grey sphere, scanned from 5 orientations of the arm. The result is the 3D max
distance (centre to centre) from the 5 spheres.
All RS5 scanning specifications are achieved with an Absolute Arm mounted on a base plate or magnetic
base plate and a matte grey sphere artefact of 25.4mm diameter under stable environment conditions.
All HP-L-20.8 scanning specifications are achieved with an Absolute Arm mounted on a base plate or
magnetic base plate and using a HP-L-20.8 zoom setting 2A (mid-range scan width 63mm) and a matte
grey sphere artefact of 25.4mm diameter under stable environment conditions.
The accuracy specifications are not guaranteed for a use with any other accessory such as stand.
Absolute Arm 7-Axis Scanning System Accuracy (L
DIA
)
Model
Size
RS5
L
DIA (mm)
HP-L-20.8
L
DIA (mm)
83 series
8320-7
2.0m (6.5ft)
0.062
0.062
8325-7
2.5m (8.2ft)
0.068
0.068
8330-7
3.0m (9.8ft)
0.092
0.092
8335-7
3.5m (11.5ft)
0.105
0.105
8340-7
4.0m (13.1ft)
0.122
0.122
8345-7
4.5m (14.8ft)
0.172
0.172
85 series
8520-7
2.0m (6.5ft)
0.045
0.045
8525-7
2.5m (8.2ft)
0.048
0.048
8530-7
3.0m (9.8ft)
0.066
0.066
8535-7
3.5m (11.5ft)
0.080
0.080
8540-7
4.0m (13.1ft)
0.091
0.091
8545-7
4.5m (14.8ft)
0.148
0.148
87 series
8725-7
2.5m (8.2ft)
0.044
0.044
8730-7
3.0m (9.8ft)
0.058
0.058
8735-7
3.5m (11.5ft)
0.071
0.071
8740-7
4.0m (13.1ft)
0.082
0.082
8745-7
4.5m (14.8ft)
0.127
0.127
