Installation
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │85
D.2.2 EXTRACT THE ARM FROM THE CASE
1. Carry the case by the handle, case on the wheels
2. Open the 4 locks
3. Hold the A axis and the E axis and lift the arm straight from the case
