Hexagon Absolute Arm RS5 User Manual

Components description
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │22
Absolute Arm 85 series
Fig. 11 : Absolute Arm 85 overview
a. Counterbalance cradle
b. “Zero-G” counterbalance
c. Counterbalance lock
d. Arm handle
e. Control Pack
f. Base of the arm
g. Mounting ring nut
h. Mounting base (depending on the option)
i. Spin Knob
j. Spin Grip
k. Arm wrist
l. Buttons
d
A
b
c
n
h
g
f
a
o
k
l
m
e
i
j
B
C
E
D
F
Fig. 12 : 7-axes Wrist
m. Contact probe
n. Status pictograms
o. On/Off button
l
k
G
F
