D.1 MOUNTING BASE
The Absolute Arm offers several different mounting possibilities.
Standard base is a simple Mounting ring on a base plate. Optional supports are available (Standard
Magnetic base, Circular magnetic base, mobile stand, heavy base, complete worktable, raisers, vertical
support …).
The Absolute Arm 1.2 series is normally using a fixed base plate but can also be mounted on all the
standard supports through an accessory mounting ring adapter (option).
The arm is designed to be used in a standing-up position. Hexagon Manufacturing Intelligence cannot
guarantee any damage due to incorrect orientation of the arm, or incorrect measurement accuracy.
For a complete list of accessories, consult the product catalogue.
For further details on each accessory, please read the applicable technical sheet.
