Hexagon Absolute Arm RS5 User Manual

Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │222
I.4.2 HP-L-20.8 SCANNER SPECIFICATIONS
Dimensions
Scan mode max Points
Mode
Line width
(mm)
20 %
(HD1)
40 %
(HD2)
60 %
(HD3)
80 %
(HD4)
100 % (HD5)
0C
220
801
1601
2401
3201
4001
1C
130
501
1001
1501
2001
2501
2B
63
501
1001
1501
2001
2501
2A
1001
2001
3001
4001
5001
3C
51
201
401
601
801
1001
4A
25
401
801
1201
1601
2001
(2.5% / 5% / and 10 % are subdivisions of HD1-20%)
Scan mode Pitch
Mode
Line width
(mm)
20 %
40 %
60 %
80 %
100 %
0C
220
0.275
0.137
0.092
0.069
0.055
1C
130
0.250
0.125
0.083
0.062
0.052
2B
63
0.120
0.060
0.040
0.030
0.025
2A
0.063
0.031
0.021
0.016
0.013
3C
51
0.252
0.126
0.084
0.063
0.050
4A
25
0.063
0.031
0.021
0.016
0.013
Scan mode max Points rate (Pts/s)
Mode
Line width
(mm)
20 %
40 %
60 %
80 %
100 %
0C
220
30037
60037
90037
120037
150037
1C
130
25450
50850
76250
101650
127050
2B
63
25050
50050
75050
100050
125050
2A
28528
57028
85528
114028
142528
3C
51
20100
40100
60100
80100
100100
4A
25
20050
40050
60050
80050
100050
