Components description

H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │41

B.5.2 PISTOL GRIP

The pistol grip of the 7 axes wrist can be customized:

• For measurements with a difficult access, the pistol grip can be easily removed from the wrist, getting

a slim configuration.

Standard configuration

Slim configuration

NOTICE

When using the Slim configuration, put the hands on the Nose Cone.

• To adjust the ergonomics to the user, 3 sizes of hand grip are available and can be easily switched.

Small Standard Large
