Components description
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │21
B. COMPONENTS DESCRIPTION
B.1 ARM DESCRIPTION
Absolute Arm 83 series
Fig. 9 : Absolute Arm 83 overview
a. Counterbalance cradle
b. “Zero-G” counterbalance
c. Counterbalance lock
d. Arm handle
e. Control Pack
f. Base of the arm
g. Mounting ring nut
h. Mounting base (depending on the option)
d
A
b
c
l
h
g
f
a
m
i
j
k
e
B
C
D
E
F
j
i
G
F
Fig. 10 : 7-axes Wrist
i. Arm wrist
j. Buttons
k. TKJ probe
l. Status pictograms
m. On/Off button
