H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │204

Arm base

Fig. 43 : Absolute Arm Compact base dimensions

Fig. 44 : Absolute Arm base dimensions

Travel case dimensions and weights

Fig. 45: Travel case dimensions

Arm size

Size (mm)

Weight

(

)

(kg)

A x B x C

1200

360 x 1330 x 605

2000

2500

3000

360 x 1630 x 605

3500

4000

360 x 1930 x 605

4500

Accessory

case

101 x 420 x 260

*: The weight of the travel case includes all accessories inside the case
