Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │223
Scan mode lines
Mode
Width (mm)
Angle (°)
Line Rate (Hz)
Nominal
Min
Max
0C
219.90
176
231
57.6
37.5
1C
129.97
104
148
36.0
50.8
2B
63.35
51
75
18.0
50.0
2A
28.5
3C
50.53
40
60
14.4
100.0
4A
25.17
20
30
7.2
50.0
Other specifications
TCPIP address
192.168.150.100
TCPIP port
53584
Warm-up time
The Power LED on the sensor indicates readiness to measure. Once the LED is solid, the sensor is ready
to measure within specified accuracy limits. While the LED is flashing, the sensor is warming up. Using
the sensor while the LED is flashing means results may be out of specification.
The maximum warm-up time for 208 in an ambient temperature between 12°C and 32°C is 5 minutes. If
the ambient temperature is lower than 12°C, the warm-up time is longer.
