Hexagon Absolute Arm RS5 User Manual

Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │214
I.3.4 TUBE PROBES SPECIFICATIONS
The full tube measurement system accuracy is defined exclusively with the new tube probe generation
(rebranded tube probes) and can’t be applied with the previous tube probe versions.
Type
Size
Tube probe alone accuracy
Global accuracy on the arm with
Tube probe
1
12.5
±
0.1 mm
E
UNI.MPE
+ 0.1mm
2
25
3
50
4
75
5
100
6
150
The tube measurement system accuracy is defined as following:
Accuracy = Volumetric arm accuracy (E
UNI.MPE
) + Tube probe accuracy
E.g. Tube measurement system accuracy with an Absolute Arm 8325T:
Accuracy = 0.058mm + 0.1mm = 0.158mm
