B.3.1 CONNECTION / DISCONNECTION OF THE PLUGS
The arm is equipped with high-reliability and IP certified plugs.
Only cables provided by Hexagon Manufacturing Intelligence can be used on the arm.
To connect a cable,
1. Approach the plug to the connector of the arm
2. Align the red or green dot on both sides and push the plug until a “click” can be heard.
To disconnect the cable from the arm, hold the body of the plug and pull it back.
“Click”
