Installation
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │81
D.1.8 STANDS
Adjust the stand to the desired height and ensure its rigidity, then install the arm on the mounting ring.
NOTICE
Bad installation or stability: Wrong measurements
► Read carefully the manual of your stand to ensure it is installed securely
Light Tetralock portable stand
NOTICE
► The Tetralock can be used only for arms up to 3.5m size.
► Always ensure that feet, height adjustments and locking horizontal bars are well tightened before any
measurement campaign.
► Place the tripod on a stable and clean floor.
Heavy duty stands
NOTICE
Always ensure that the wheels are “off” and Height setting is locked before any measurement campaign.
