Wrap expedition box
Arm size
Inside dimensions
Overall dimensions
1200
Small
1485 x 745 x 620
1520 x 780 x 783
2000
2500
3000
Medium
1780 x 745 x 620
1810 x 780 x 783
3500
4000
Large
2080 x 745 x 620
2110 x 780 x 783
4500
Mounting ring
Fig. 46 : Mounting ring dimensions
W
140
630
