Measure with the arm
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │155
F.6.9 SCANNING PROFILES
To facilitate the configuration of the scanning parameters when typical settings are used, RDS can record
a set of parameters into a scanning profile.
RDS can memorize scanning profiles for each type of Laser scanner. It means that the set of parameters
(scanning mode, filters…) can be saved into different configurations.
Save a profile (Advanced user profile)
1. Access RDS Control Panel, Tab Scanner
2. Select the profile to modify
3. Set the parameters according to your needs (current profile becomes “Customized”).
4. Click on “Save”
5. Give a name for the profile (existing profile can be selected from the drop-down list to be overwritten)
6. Click on “Validate”
Use a profile (all users)
There are different ways to select and use a profile:
• From RDS Control Panel: access the tab “Scanner” and select the profile in the drop-down list (don’t
forget to save Control Panel).
• From the RDS Scanning window: directly select the profile from the drop-down list on the RDS Scanning
window.
• From the Quick Access Menu
Control Panel
Scanner
Save
Create a new profile or overwrite an existing
one.
Cancel
OK
▼
Surface
Default
Surface
Default
