Hexagon Absolute Arm RS5 User Manual

Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │191
I.2.10 POWERINSPECT
Trigger button
3-States button - Left
3-States button - Right
Short
Hit Pt. / Scan
Delete last point
Validate
Long
Burst Pts / Scan
Delete all points
At first start of PowerInspect, or through the menu, select the type of measuring system: “Hexagon RDS”.
To connect PowerInspect to the arm, click on the “connect” button.
Wait few seconds after press buttons to start first scan.
It is strongly recommended to use scanner filters to decrease the number of points for
geometric items.
