Hexagon Absolute Arm RS5 User Manual

Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │220
I.4 HEXAGON
®
SCANNERS SPECIFICATIONS
I.4.1 RS5 SCANNER SPECIFICATIONS
Technical Specifications
Stand Off
165 ± 50 mm
Laser line length
115 mm
Max USB scanning rate
100 Hz
Automatic exposure
Not available
Max Points per stripe
7524
Line resolution (mid-range)
0.015
Max Data rate
752 400 pts/s
Scanner accuracy
30 µm
Ambient light immunity
10 000 Lux
Triangulation angle
24°
Weight
440 g
Available Temperature
5 to 40° C
PC Communication
Ethernet LAN! On-board Gigabit required.
Storage Temperature
-25 to 70 °C
Laser Line
Laser Point Guide
Laser class
2M
2
Maximum optical output
7 mW
< 0.8 mW
Wavelength
658nm
635nm
Cleaning
To clean the front glasses of the RS5 Scanner, use compressed air to
remove loose particles.
(If you use compressed air from a fingertip dispenser please be aware
that in some cases the spray could contain also parts of the propellant
which causes pollutions).
For removing tough pollutions, use wadded-cotton tips. These tips have
to be used in a careful way and only with very less pressure to avoid
injuring the surface of the glass.
Cleaning alcohol such as 3M® “Surface cleaner” can be used.
