Installation
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │86
D.2.3 SETUP THE ARM
Absolute Arm Compact (1.2)
1. Extract the arm from the case
2. Simply put down the arm and lay down its elbow on a level and stable surface
3. Extract the counterweight from the case
4. Approach the counterweight from the back of the arm and clip it.
Lift up the arm and bring it in its rest position (front or back)
The 1.2 arm doesn’t need to be fixed to the work surface. However, in case of a low-quality surface
(slippery surface, not stable …), it is highly recommended to fix the arm (screws, magnets…)
