Components description
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │34
B.2.5 FP4 SETUP
The HP-LC-200 (FP4) must be mounted on and dismounted from the FP4 adapter each time the arm needs
to be placed in its case.
1. Approach and plug the FP4 to the Data port.
2. Insert the hinges of the doors in the notches and close the doors.
3. Insert and tighten each of the 4 screws.
