Installation
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │73
D.1.1 ABSOLUTE ARM COMPACT 1.2 BASE
Default use
The 1.2 series arms are designed to be used simply laid on a stable work surface. It means that it normally
doesn’t need to be fixed.
However, in some circumstances, it may be advised to get more security regarding the stability.
The 1.2 series arm provides several possibilities to securely fix the arm.
Fix with screws
3 holes are available on the base plate of the 1.2 series arm to be able to fix it using screws.
Each slot hole is located on a mobile (rotating) and removable circular plate, that allow freedom, to fit on
any support.
