3. On next window, select “type of machine”: “Perceptron via Scanworks”
4. On same window, for Protocol version, choose “ROMER RDS”.
5. Tick “Automatically recall last probes file” then click on “Next”.
6. Finish the configuration by clicking on “Save”
I.2.13 GEOMAGIC
Trigger button
3State button - Left
3State button - Right
Short
Hit Pt. / Scan
Validate / OK
Long
Configuration for probing or HEXAGON
®
scanners
After Geomagic installation, install “Absolute Probing” and “Absolute Scanning” plug-ins
In Qualify or Studio, «material” tab, select “Hexagon Absolute Probing” or “Hexagon Absolute Scanning”
Configuration for Perceptron
After Geomagic installation, run “Perceptron SetUp.exe” plug-ins installation.
In Qualify or Studio, «material” tab, select “Perceptron Plug-ins:
