B.8 TRAVEL CASE
The Absolute Arm is delivered in a robust and easy handling travel case.
For the manipulation, the case is equipped with 3 handles, and 2 enforced wheels
Overview
Fig. 24 : Travel case description.
a. Lid
b. Identification of the arm
c. Opening locks
d. Handles
e. Wheels
Inside components (except 1.2 series)
Fig. 25 : Travel case description
a. Absolute Arm.
b. Verification bar (depends on the options)
c. Cables + Dust protection cover
d. Accessories case
e. Cables
f. Mounting base
e
a
c
d
b
a b
c d e f
