I. APPENDIX
I.1 TERMINOLOGY, SYMBOLS
Terminology
Description
6axes
Applies to all 6 axes arms (83, 85 and 87 series)
SE arms
Applies to all 7 axes SE arms (83, 85 and 87 series)
SI arms
Applies to all 7 axes SI arms (83, 85 and 87 series)
83
Applies to all 83 series arms (6 axes, SE, SI)
85
Applies to all 85 series arms (6 axes, SE, SI)
87
Applies to all 87 series arms (6 axes, SE, SI)
1.2
Applies to the specific 1200 size arm.
83-6
85-6
83SE
87SI
…
Applies to a specific type of arm
Symbols
Symbol
Description
General danger
Standard feature
Correct operation
Electric risk
Opt.
Feature is optional
Chemical risk
Incorrect operation
Pinch Risk
IEC 60417-5031: Direct Current
Cutting Risk
For Absolute Arm, specific USB cable
only
Laser risk
Read the manual before use
